This Hot dip Galvanized I Beam is manufactured by Shixinda's factory using a regular hot-dip galvanizing process. The zinc layer is uniform and thick, with strong adhesion, and is not prone to peeling or missing coating. It has excellent rust prevention and corrosion resistance. It can be adapted to complex working conditions such as outdoor, open-air, seaside salt spray, and chemical dampness. Its service life is much longer than that of ordinary black materials and cold-dipped profiles, significantly reducing the maintenance costs for rust removal and painting in the later stage of the project. The overall cost performance is extremely high. The company always has 10# - 63# full specifications in stock, with complete regular sizes of 6 - 12 meters, and sufficient inventory and stable supply.
It is equipped with its own deep processing workshop, which supports customized cutting, punching, bending and other precision processing services. It can be directly installed upon leaving the factory, effectively shortening the construction period. Relying on the storage advantage of the Tianjin production site, there is no middleman markup, the quotation is transparent and affordable. The goods can be quickly loaded and dispatched for delivery, and support nationwide distribution. In addition, the company has complete foreign trade qualifications, which can handle customs declaration, container loading, and issue customs clearance documents, covering both domestic projects and overseas export orders, and fully meeting the diversified procurement needs of customers.
1. Steel base material standard: GB/T 706-2016 Hot-rolled Steel Sections
2. Galvanizing layer anti-corrosion standard: GB/T 13912-2020 Hot-dip Galvanized Layer Specification
3. Main materials: Q235B (ordinary load-bearing), Q355B (low alloy high strength)
4. Zinc layer thickness: Regular 80–120 μm; Coastal / Chemical corrosion environment 120–150 μm
|
Model No. |
Section Dimension (Height × Flange Width × Web Thickness, mm) |
Theoretical Weight (kg/m) |
|
10# |
100×68×4.5 |
11.2 |
|
16# |
160×88×6 |
20.5 |
|
20a# |
200×100×7 |
27.9 |
|
20b# |
200×102×9 |
31.1 |
|
25a# |
250×116×8 |
38.1 |
|
30a# |
300×126×9 |
48.0 |
|
40a# |
400×142×10.5 |
67.6 |
|
56a# |
560×166×12.5 |
106.0 |
Our Hot Dip Galvanized I Beam is processed using the hot-dip galvanizing technique, with a zinc layer of 80–150 μm. The zinc and steel are metallurgically bonded and do not peel off. It can be used in outdoor open-air, seaside salt spray, and chemical damp environments, and has a much longer service life than black paint or spray-painted I-beams. It requires no rust removal and painting for ten years, significantly reducing the cost of post-installation labor maintenance.
The base material follows the GB/T706 national standard for hot-rolled I-beams, including Q235B ordinary model and Q355B high-strength model. The cross-section has strong bending resistance and can meet the load requirements for main beams, columns, and supports. It is suitable for factory buildings, photovoltaic systems, municipal projects, bridges, and other load-bearing structures. A complete material quality guarantee certificate is provided.
The finished galvanized surface is smooth and flat, allowing for direct drilling, cutting, welding, and bolt assembly. At the factory, it can be cut to the required length and pre-drilled, eliminating the need for secondary anti-corrosion treatment on-site, which shortens the construction period and reduces labor costs.
Black paint I-beams are cheaper to purchase, but the annual cost of rust removal and painting materials and labor is high. Galvanized I-beams undergo one-time processing and have lifelong anti-corrosion, resulting in a lower total cost over the long term. Bulk purchases can enjoy tonnage price discounts.
Photovoltaic support main beams, outdoor factory steel structures, vehicle shelters and corridors, municipal guardrails, lamp bases, ports and docks, power poles, water treatment equipment supports, indoor and outdoor anti-corrosion projects - all covered.
The fully automated hot-dip galvanizing production line includes acid washing, auxiliary plating, high-temperature zinc immersion, and passivation processes. There is no missing plating or accumulated zinc burrs.
Full specifications from 10# to 63# are in stock, with standard lengths of 6/9/12 meters. Non-standard lengths can be cut. It can be paired with bending, drilling, packaging, and is directly dispatched from the Tianjin warehouse. Full truckload or less-than-truckload transportation is available. For overseas trade, customs declaration and container loading can be handled.
